Float Switch Fluid Water Level Sensing Switch Sensor 12v 24v

Product Description:

Horizontal float sensor switch is installed on the side of liquid level sensor controller, automatic water pump controller, water tank pool.
Float switch is a device used to sense the liquid level in the tank. It can activate pumps, indicators, alarms or other devices.
Use them with , sea water tanks, fresh water tanks, gardening, aquariums for power head control, pet bowls, fish tanks, filtration, heating or any of your projects.
Does not contain for Mercury.


Product specifications:

Type:brand new
Material: PP
Contract rating (maximum): 10W
Switching voltage (Max): 110VDC
Switching current (Max): 0.5A
Breakdown voltage (Max): 220VDC
Carrying current (maximum): 1A
Contract resistance (maximum): 100 OHM
Temperature class: -10 ~ +60 degrees Celsius

Input voltage: 12V, 24v

Package Included:

1 *Liquid float switch


Note:

1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2.Please allow slight manual measurement deviation for the data.
