Thiết bị Phân Tần Behringer ULTRADRIVE PRO DCX2496

CHI TIẾT SẢN PHẨM

Bộ xử lý tín hiệu Behringer ULTRADRIVE PRO DCX2496 là sản phẩm của thương hiệu Behringer thuộc dòng Compressors/Limiters được nhập khẩu và phân phối chính hãng bởi Công ty TNHH HOÀNG BẢO KHOA

• Ultra-High Digital 24-Bit/96 kHz Loudspeaker Management System.
• 3 analog inputs (one suitable as digital stereo AES/EBU input) and 6 analog outputs for maximum flexibility.
• High-end 96 kHz converters for  signal integrity and wide dynamic range (120 dB).
• Integrated sample rate converter for easy connection of external digital signals with sampling rates from 32 to 96 kHz.
• Precise Dynamic EQs for level-dependent equalization and extremely musical Parametric EQs, selectable for all inputs and outputs.
• Several types of EQs (LP/BP/HP) for each input and output.
• "Zero"-attack Limiters on all output channels for optimal speaker protection.
• Four different mono and stereo output operating modes.
• Individual crossover filter types (Butterworth, Bessel and Linkwitz-Riley) with selectable roll-off characteristics from 6 to 48 dB/octave.
• Adjustable Delays for all inputs and outputs—allow manual or automatic correction for room temperature, phase and arrival time differences.
• Additional Sum signal derived from the A/B/C inputs offers a fourth internal input signal.
• Free ULTRADRIVE PRO software enables total control via PC through RS-232 and RS-485 interfaces.
• Link option via RS-485 network interface enables cascading of several ULTRADRIVE PROs.
• 60 user-defined internal presets storable.
• Servo-balanced, gold-plated XLR connectors for all inputs and outputs.
• Internal switch-mode power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving.
• High-quality components and exceptionally rugged construction ensure long life.
• 1-Year Warranty Program**.
• Conceived and designed by BEHRINGER Germany.
•



  Thông số kỹ thuật Bộ xử lý tín hiệu Behringer ULTRADRIVE PRO DCX2496:



  Frequency Response	10Hz to 35kHz, -1dB
  Dynamic Range	109dB
  Input Connections	3 x XLR
  Output Connections	6 x XLR
  Input Impedance	20kΩ @ 1kHz
  Output Impedance	160Ω @ 1kHz
  Maximum Input Level	+22dBu
  Maximum Output Level	+22dBu
  Sample Rate	32kHz to 96kHz
  RTA Mic Phantom Voltage	+15V
  Crosstalk (Main Outputs)	-100dB @ 10dBu In
  THD & Noise	0.007% @ 0dBu In
  Dimensions	19" x 8.5 x 1.75" (483 x 217 x 45mm)
  Weight	6.6 lbs (3 kg)

  Packaging Info

  Package Weight	6.3 lb
  Box Dimensions (LxWxH)	18.11 x 8.661 x 3.465"
