Compatibility
Intel LGA2066/2011/1700/1200/1151/1150/1155/1156
AMD AM5/AM4
TDP
180W
Overall Dimension
124×72×151mm (L×W×H)
Heatsink Material
4×Ф6mm Heatpipe(Direct Touch)+Aluminum Fin
Weight
550g (Heatsink+Fan)
Fan Dimension
120×120×25mm
Fan Speed
600±200~1500±10%RPM(PWM)
Max. Air Flow
70CFM
Max. Static Pressure
2.15mmH2O
Noise
28.9dB(A) Max.
Rated Voltage
12VDC
Operating Voltage
10.8～13.2VDC
Started Voltage
7VDC
Rated Current
0.15A
Power Input
1.8W
Bearing Type
Hydraulic Bearing
Connector
4Pin PWM
