Switch Cisco Catalyst WS-C3650-24PS-L - 24 ports

CHI TIẾT SẢN PHẨM

Switch Cisco WS-C3650-24PS-L được thiết kế để phù hợp với lớp Aggregation / Distribution  (Lớp trung gian, Lớp phân phối) hoặc lớp Core (Lớp lõi). Switch Cisco WS-C3650-24PS-L cung cấp 24 10/100/1000 Ethernet PoE+ and 2x10G Uplink ports, with 640WAC power supply, 1 RU, LAN Base. WS-C3650-24PS-L sử dụng nguồn điện AC 220V.

Thông số kỹ thuật chi tiết của WS-C3650-24PS-L

Hardware Specifications
10/100/1000 Ethernet Ports	24 PoE+
Fixed Uplinks	4 x Gigabit Ethernet with Small Form‑Factor Pluggable (SFP)
Default AC Power Supply	640 WAC
Available PoE Power	390 W
Performance Specifications
Switching capacity	92 Gbps
Stacking bandwidth	160 Gbps
Total number of MAC addresses	32,000
Total number of IPv4 routes (ARP plus learned routes)	24,000
FNF entries	24,000 flows
DRAM	4 GB
Flash	2 GB
VLAN IDs	4,094
Total switched virtual interfaces (SVIs)	1,000
Jumbo frame	9198 bytes
Total routed ports per 3650 stack	208
Wireless
Number of access points per switch/stack	25
Number of wireless clients per switch/stack	1000
Total number of WLANs per switch	64
Wireless bandwidth per switch	Up to 20 Gbps
Supported Aironet access point series	3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040
Forwarding Rate	41.66 Mpps
Dimensions
Dimensions (H x W x D) (Inches/Centimeters)	1.73 x 17.5 x 17.625/4.4 x 44.5 x 44.8
Weight (Pounds/Kilograms)	16/7.26
MTBF Hours	528,280
Environmental Ranges
With AC Power Supply   Operating Environment and Altitude	-5ºC to +45ºC, up to 5000 feet (1500m) -5ºC to +40ºC, up to 10,000 feet (3000m) -5ºC to +35ºC, up to 13,000 feet (4000m) -5ºC to +30ºC, up to 16,400 feet (5000m)
With DC Power Supply   Operating Environment and Altitude (NEBS)	-5ºC to +45ºC, up to 5000 feet (1500m) -5ºC to +45ºC, up to 10,000 feet (3000m)
Safety and Compliance
Safety Certifications	UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition GOST NOM (obtained by partners and distributors)
Electromagnetic Emissions Certifications	47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A) AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class  KCC CNS13438 Class A EN55024 CISPR24 KN24

Các loại cable stack có thể sử dụng cho Cisco Switch WS-C3650-24PS-L:

C3650-STACK-KIT=	Cisco Catalyst 3650 Stack Module spare
STACK-T2-50CM=	Cisco StackWise-160 50CM Stacking Cable Spare
STACK-T2-1M=	Cisco StackWise-160 1M Stacking Cable Spare
STACK-T2-BLANK=	Cisco Catalyst 3650 Stacking Blank Spare

Các module quang dưới đây có thể sử dụng cho Switch WS-C3650-24PS-L

GLC-T	Module quang Cisco GLC-T 1000BASE-T, RJ-45 connector
GLC-TE	Module quang Cisco GLC-TE 1000BASE-T, RJ-45 connector
GLC-SX-MMD	Module quang Cisco GLC-SX-MMD 1000BASE-SX, MMF, DOM, 850 nm, 550m, Dual LC
GLC-LH-SMD	Module quang Cisco GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-EX-SMD	Module quang Cisco GLC-EX-SMD 1000BASE-EX, SMF, DOM, 1310 nm, 40km, Dual LC
GLC-ZX-SMD	Module quang Cisco GLC-ZX-MMD 1000BASE-ZX, SMF, DOM, 1550 nm, 80km, Dual LC
GLC-SX-MM	Module quang Cisco GLC-SX-MM 1000BASE-SX, MMF, 850 nm, 550m, Dual LC
GLC-LH-SM	Module quang Cisco GLC-LH-SM 1000BASE-LX/LH, MMF/SMF, 1310 nm, 10km, Dual LC
GLC-ZX-SM	Module quang Cisco GLC-ZX-SM 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC
GLC-BX-D	Module quang Cisco GLC-BX-D 1000BASE-BX, SMF, 1490TX 1310RX, Single LC
GLC-BX-U	Module quang Cisco GLC-BX-D 1000BASE-BX, SMF, 1310TX 1490RX, Single LC
GLC-BX40-D-I	Module quang Cisco 1000BASE-BX40 SFP, 1550NM
GLC-BX40-U-I	Module quang Cisco 1000BASE-BX40 SFP, 1310NM
GLC-BX40-DA-I	Module quang Cisco 1000BASE-BX40 SFP, 1490NM
GLC-BX80-D-I	Module quang Cisco 1000BASE-BX80 SFP, 1570NM
GLC-BX80-U-I	Module quang Cisco 1000BASE-BX80 SFP, 1490NM
GLC-2BX-D	Module quang Cisco GLC-2BX-D 1000BASE-BX10, SMF, 1310TX 1490RX, 2 single LC/PC
SFP-GE-T	Module quang Cisco GLC-T 1000BASE-T, RJ-45 connector
SFP-GE-S	Module quang CiscoSFP-GE-S 1000BASE-SX, MMF, DOM, 850 nm, 550m
SFP-GE-L	Module quang Cisco SFP-GE-L 1000BASE-LX/LH, MMF/SMF DOM, 1300 nm, 10km, Dual LC
SFP-GE-Z	Module quang Cisco SFP-GE-Z 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC
GLC-SX-MM-RGD	Module quang Cisco GLC-SX-MM-RGD 1000BASE-SX, MMF, 850 nm, 550m, Dual LC, industrial
GLC-LX-SM-RGD	Module quang Cisco GLC-LX-SM-RGD 1000BASE-LX/LH, MMF/SMF, 1300 nm, 10km, Dual LC, industrial
GLC-ZX-SM-RGD	Module quang Cisco GLC-ZX-SM-RGD 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC, industrial
SFP-GPON-B	Module quang SFP-GPON-B GPON Class B+ SFP OLT, 1490TX 1310RX
SFP-GPON-C	Module quang SFP-GPON-C GPON Class C+ SFP OLT 1490TX 1310RX
SFP-GPON-B-I	Module quang SFP-GPON-B GPON Class B+ SFP OLT, 1490TX 1310RX, industrial
SFP-GPON-C-I	Module quang SFP-GPON-C GPON Class C+ SFP OLT 1490TX 1310RX, industrial

Các module quang OEM giá rẻ sử dụng được cho WS-C3650-24PS-L

Part	Depcription
GLC-LH-SMD-CL	OEM GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-SX-MMD-CL	OEM GLC-SX-MMD 1000BASE-SX, MMF, DOM, 850 nm, 550m, Dual LC
GLC-EX-SMD-CL	OEM GLC-EX-SMD 1000BASE-EX, SMF, DOM, 1310 nm, 40km, Dual LC
GLC-T-CL	OEM GLC-T 1000BASE-T, RJ-45 connector
GLC-LH-SM-CL	OEM GLC-T 1000BASE-T, RJ-45 connector
GLC-LH-SM-CL	OEM GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-SX-MM-CL	OEM GLC-SX-MM 1000BASE-SX, MMF, 850 nm, 550m, Dual LC

Các loại nguồn và fan sử dụng cho switch cisco  WS-C3650-24PS-L:

Part Number	Description
PWR-C2-640WAC	640W AC Catalyst 3650 Series Spare Power Supply
PA-2641-1-LF	640W AC Catalyst 3650 Series Spare Power Supply
341-0531-01 A0	640W AC Catalyst 3650 Series Spare Power Supply
PWR-C2-BLANK	Power supply blank
FAN-T1	Fan module

License có thể sử dụng cho Cisco Switch WS-C3650-24PS-L

Feature License and Software Options
C3650-RTU=	Paper SW License for Cisco Catalyst 3650 Switches
L-C3650-RTU=	Electronic SW License for Cisco Catalyst 3650 Switches
C3650-24-L-S	Cisco Catalyst 3650 24-port LAN Base to IP Base Paper RTU License
L-C3650-24-L-S	Cisco Catalyst 3650 24-port Switch LAN Base to IP Base Electronic RTU License
Access Point Licenses
L-LIC-CT3650-UPG	Primary upgrade license SKU for Cisco 3650 wireless controller (e-delivery)
L-LIC-CTIOS-1A	1 access point adder license for Cisco IOS Software based wireless controller (e-delivery)
LIC-CT3650-UPG	Primary upgrade license SKU for Cisco 3650 wireless controller (paper license)
LIC-CTIOS-1A	1 access point adder license for the Cisco IOS Software based wireless controller (paper license)
