Sound card Focusrite Clarlett 4Pre

CHI TIẾT SẢN PHẨM

Product Highlights

• 4 Preamps Model the Classic ISA Design
• Low-Noise and Low-Distortion Mic Preamps
• 24-bit / 192 kHz Audio Resolution
• Low-Latency Monitoring
• 2x Monitor Outputs, 2x Line Outputs
• USB, S/PDIF, MIDI I/O, ADAT Input
• Gain Halo Meters
• 2 x Headphone Outputs
• Includes Software Bundle
• Mac, Windows



Focusrite CLARET 4PRE overview

Equally comfortable in the studio or as part of a mobile rig, the Focusrite Clarett 4Pre USB 18x6 USB Audio Interface combines 24-bit / 192 kHz A/D/A conversion, low-latency monitoring, and a multitude of I/O options with four, Air-enabled microphone preamps that can model the sound of the company's classic ISA preamps. With low noise (-128 dB EIN), low distortion, and 118 dB dynamic range, the high-performance mic preamps deliver a clean, open, and transparent sound, for accurate reproduction of the original performance.

The Clarett 4Pre USB is equipped with four front panel mic/line inputs, two of which have high-headroom instrument inputs for recording hot pickups without distortion. Each mic pre has a separate gain knob with a Gain Halo meter that makes it easy to set the correct input level. The interface also provides two line level outputs, two monitor outputs with anti-thump technology, MIDI I/O, stereo S/PDIF I/O, and eight channels of ADAT inputs to expand your setup. The front panel features two 1/4" headphone outputs with independent volume controls. A pair of +48V phantom power switches allow you to turn on phantom power for condenser microphones on channels 1 & 2 and 3 & 4 respectively.

The Clarett 4Pre USB offers a comprehensive software package that includes the Focusrite Red Plug-In Suite with accurate models of the Red 2 EQ equalizer and Red 3 Compressor, the Softube Time and Tone Bundle with reverb, delay, mastering, and distortion plug-ins, a Loopmasters library with 2GB of royalty-free samples, and more. Also provided is the Focusrite Control software that enables you to configure your routing and monitor mixes from Mac and Windows computers, or iPad, iPhone, and iPod touch devices.

Key Features

• Four Air-enabled mic preamps emulate the sound of the company's original ISA mic preamp
• Low-noise (-128 dB EIN) mic preamps with low distortion and up to 118 dB dynamic range
• Precision 24-bit / 192 kHz A/D and D/A conversion
• Record with low latency through amp simulators and effects plug-ins
• Four mic/line XLR-1/4" combo inputs on front-panel—two of them with high-headroom instrument inputs for recording hot pickups without distortion
• Four additional line 1/4" jack inputs on rear panel
• Switchable 48V phantom power
• Stereo S/PDIF I/O
• Eight channels of ADAT inputs to expand system
• 5-pin MIDI I/O
• Two monitor outputs with anti-thump technology
• Two additional line outputs
• Two headphone outputs with independent volume controls
• Gain Halo illuminated rings around the gain controls light up green when there's signal present and turn red when the level is too high
• Supports any Mac or Windows computer with USB 2.0 and above

Included Software

Focusrite Control Software

• Control software enables you to configure your routing and monitor mixes from Mac or Windows computers, and iPad, iPhone, or iPod touch

XLN Audio Addictive Keys

• One of four Addictive Keys keyboard instruments

Focusrite Red Plug-In Suite

• Accurately models Focusrite's classic Red 2 equalizer and Red 3 compressor

Softube Time and Tone Bundle

• Four of Softube's reverb, delay, mastering, and distortion plug-ins

Focusrite Plug-In Collective

• Exclusive offers, tutorial content, and more, from some of the most innovative and prestigious plug-in companies

Ableton Live Lite

• Customized version of the music production software Ableton Live

Loopmasters

• 2GB library of royalty-free samples



Focusrite CLARET 4PRE specs

Connectivity

I/O

4 x combo XLR-1/4" / 6.3 mm TRS mic/line/instrument inputs, balanced (front panel) 4 x 1/4" / 6.3 mm TRS line inputs, balanced (rear panel) 2 x 1/4" / 6.3 mm TRS monitor outputs, balanced 2 x 1/4" / 6.3 mm TRS line outputs, balanced 2 x 1/4" / 6.3 mm TRS stereo headphone outputs (front panel) 1 x ADAT optical, 8-channel input 1 x S/PDIF, stereo input 1 x S/PDIF, stereo output 1 x 5-pin MIDI in 1 x 5-pin MIDI out 1 x USB (2.0 and later)

Digital AD/DA Performance
Sample Rates	44.1, 48, 88.2, 96, 176.4, 192 kHz
Bit Depth	24-bit

Microphone Inputs
Frequency Response	20 Hz to 35 kHz (±0.5 dB), at minimum gain
Dynamic Range	> 118 dB
THD+N	< 0.0009%
Noise EIN	< -128 dB, A-weighted
Maximum Input Level	+18 dBu, at minimum gain
Gain Range	+57 dB

Line Inputs 1-4 (Variable Gain)
Frequency Response	20 Hz to 35 kHz (± 0.5 dB), at minimum gain
Dynamic Range	118 dB
THD+N	0.001%
Maximum Input Level	+26 dBu, at minimum gain
Gain Range	+57 dB

Line Inputs 5-8 (Fixed Gain)
Frequency Response	20 Hz to 35 kHz (± 0.5 dB), at minimum gain
Dynamic Range	118 dB
THD+N	0.001%
Maximum Input Level	+26 dBu, at minimum gain

Instrument Inputs
Frequency Response	20 Hz to 35 kHz (± 0.5 dB), at minimum gain
Dynamic Range	117 dB
THD+N	0.001%
Maximum Input Level	+14 dBu, at minimum gain
Gain Range	+ 57 dB

Line Output
Dynamic Range	118 dB
Maximum Output Level	Line/TRS Outputs: +18 dBu, at minimum gain (0 dBFS, balanced)
THD+N	0.0006%

Headphone Outputs
Dynamic Range	115 dB, A-weighted
THD+N	0.0003%
Maximum Output Level	15 dBu

General
System Requirements	Windows: 7, 8, 8.1, 10 Mac OS X / macOS: 10.11 (El Capitan), 10.12 (Sierra), 10.13 (High Sierra)
Dimensions (H x D x W)	2.50 x 8.74 x 7.56" / 63.50 x 222.00 x 192.02 mm
Weight	4.21 lb / 1.91 kg

Packaging Info
Package Weight	5.95 lb
Box Dimensions (LxWxH)	11.5 x 11.4 x 5.2"

In the Box

Focusrite Clarett 4Pre USB 18x6 USB Audio Interface

• USB Cable with USB Type-A Connector
• USB Cable with USB Type-C Connector
• Power Supply
