Original USB ACR122U NFC Card Reader Writer 13.56Mhz RFID Copier Duplicator

Please note that there is no CD in the package now.

Warning: This is a research and development tool. It has not been evaluated for compliance with regulations governing transmission and reception of radio signals. You are responsible for using this product in compliance with your local laws.

Overview:

The ACR122U is a PC-linked contactless smart card reader/writer developed based on the 13.56 MHz Contactless (RFID) Technology. Compliant with the ISO/IEC18092 standard for Near Field Communication (NFC), it supports not only IC and ISO 14443 A and B cards but also NFC and FeliCa contactless technologies.

ACR122U is compliant with both CCID and PC/SC. Thus, it is a plug-and-play USB device allowing interoperability with different devices and applications. With an access speed of up to 424 kbps and a full USB speed of up to 12 Mbps, ACR122U can also read and write more quickly and efficiently. The proximity operating distance of ACR122U is up to 5 cm, depending on the type of contactless tag in use.

In order to increase the security level, ACR122U can be integrated with an ISO 7816-3 SAM slot. Furthermore, the ACR122U NFC Reader is available in module form, permitting easy integration into bigger machines, such as POS terminals, physical access systems and vending machines.

The is ideal for both secure personal identity verification and online micro-payment transactions. Other applications of the ACR122U include access control, e-payment, e-ticketing for events and mass transit, toll road fare collection and network authentication.

Features:
CCID-compliant
PC/SC-compliant
Read/write speed up to 424 kbps
Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)
Supports ISO 14443 Type A and B, FeliCa, and all 4 types of NFC (ISO/IEC 18092) tags
Supports new IC Ultralight C (via pseudo APDUs) and IC Plus SL1 (4 Byte UID, via pseudo APDUS) and SL3Supports all 3 modes of NFC: reader, card emulation and peer-to-peer modes
Built-in anti-collision feature (at least 1 card is detected when multiple cards are presented)
USB PnP
User-controllable bi-color LED

Application
Network access control
Micro-payment
NFC mobile tag
Public transportation terminals
Automatic fare collection
Physical access control
Customer loyalty
Time and attendance
Contactless public phones
Vending machines

Technical Specification

Dimensions	98 (L) x 65 (W) x 12.8 (H) mm
Weight	70 g
Interface	USB Full Speed
Operating Distance	≤ 50mm (depends on tag type)
Supply Voltage	5V DC
Supply Current	200mA (operating); 50mA (standby); 100mA (normal)
Operating Temperature	0 - 50°C
Operating Frequency	13.56 MHz
Smart Card Interface Support	ISO14443 Type A & B IC card FeliCa 4 types of NFC (ISO/IEC18092) tags
Compliance/Certifications	PC/SC, CCID, CE, FCC, VCCI, RoHS Compliant, USB Full Speed Microsoft ® WHQL: 2000, Server 2003, XP, Vista, Server 2008, Server 2008 R2, 7
Operating System Support	Win 98, Win ME, Win 2000, Win XP, Win Vista, Win 7, Win Server 2003, Win Server 2008 Win XP x64, Win Vista x64, Win 7 x64, Win Server 2003 x64, Win Server 2008 x64, Win Server 2008 R2 x64 Windows CE 5.0 Linux Mac Android3.1andabove

Packing:

5PCS xACR122U-A9 NFC Card Reader
