Ổ cứng WD My Cloud PR2100 0TB WDBBCL0000NBK

CHI TIẾT SẢN PHẨM

Bộ lưu trữ mạng Nas WD My Cloud PR2100 rất phù hợp cho các công ty về thiết kế đồ họa, dựng phim, đáp ứng việc lưu trữ những file dữ liệu dung lượng lớn 4K, hình ảnh, video chất lượng cao; các doanh nghiệp xử lý khối lượng công việc lớn; các chuyên gia IT hay các cá nhân muốn khám phá, trải nghiệm những tính năng ưu việt của dòng nas My Cloud PR2100.

My Cloud Pro thiết kế hướng tới người dùng thiết kế - tương thích với Adobe Creative Cloud, dịch vụ lưu trữ đám mây của bộ phần mềm Adobe Creative nổi tiếng.

Tên sản phẩm: My Cloud PR2100

Mã sản phẩm: WDBBCL0000NBK

Dung lượng: 0TB (không bao gồm ổ đĩa cứng)

Số khay ổ đĩa: 2

Hệ điều hành: My Cloud OS 3

Bộ vi xử lý: Intel Pentium N3710 Quad-core 1.6GHz

Bộ nhớ trong: 4GB

Giao tiếp: 02 Gigabit Ethernet (10/100/1000 MB/s),  2xUSB 3.0 (1 cổng mở rộng phía sau, 1 cổng phía trước copy trực tiếp tới My Cloud)

Cổng nguồn: 2 (bộ sản phẩm gồm 01 adapter 12 V - 4.0A - 48 W)

Thiết lập RAID: 0,1, JBOD & spanning. Tính năng Hot-swap cắm nóng ổ cứng.

Truy cập từ xa

• Ứng dụng My Cloud trên thiết bị di động
• Truy cập từ xa qua web mycloud.com

Các phần mềm hỗ trợ: Truy cập: http://support.wdc.com/downloads.aspx?lang=en&f wdsfMyCloud_PR2100

• WD Access
• WD SmartWare
• WD Sync

Kích thước vật lý: HxDxW 147 mm x 216 mm x 108 mm

Nhiệt độ: Hoạt động 0° C to 35° C
                 Không hoạt động: -40° C to 70° C

Tương thích: Windows/Mac

• Windows 10, 8, 7
• Mac OS X Mavericks, Mountain Lion, Lion, Snow Leopard
• Các thiết bị hỗ trợ DLNA/UPnP
• Kết nối Internet để truy cập từ xa

Thông số kỹ thuật nâng cao

Network Protocols

• DHCP Client or Static IP
• NTP Client
• Dynamic DNS (DDNS)
• Apple Bonjour and Windows Rally
• Jumbo frame support up to 9K
• VLAN (802.1Q)
• Link Aggregation and failover for 2 Gigabit Ethernet ports
• UPnP port forwarding
• IPv6
• iSCSI
• SSH

Network File Services

• CIFS/SMBv3 for Windows, Mac OS X and Linux
• NFSv3 for Linux and UNIX
• AFP for Mac OS X
• Microsoft Distributed File System (DFS)
• WebDAV Server

Security

• Active Directory support for Windows Server
• Volume Encryption (256 bit AES)

File System

• EXT4 for internal HDD
• Support following formats for externally attached USB drives
  • FAT/FAT32
  • NTFS (read and write capability)
  • HFS+J (case sensitive)
  • Linux EXT2, EXT3, EXT4

FTP Server

• Support Port Setting
• Set port range of passive FTP
• Option to report external IP in PASV mode
• Client language selection
• Anonymous FTP
• Secure FTP Support
• Support File eXchange Protocol (FXP)
• FTP bandwidth restriction (upstream/downstream)
• IP address block (block access from undesired IP address)

Download Management

• HTTP downloads from a URL to a user specified folder on the NAS
• FTP downloads of files or folders from an FTP server to another files/folders on the NAS
• P2P Download Manager

Disk management

• RAID: JBOD, spanning, 0/1
• RAID migration
  • JBOD to RAID 1
• Hot swapping
• Disk roaming
• Array roaming

Power Management

• Drive Spin Up/Down (including Attached WD USB drives)
• Automatic power recovery (with UPS)
• Schedule power on/off
• Graceful shutdown on UPS low battery
• FAN Control
• Network UPS
• Wake On LAN

Remote Access

• My Cloud and WD Photos mobile app
• My Cloud desktop app

User/Group Management

• Max No. of Users: 512 for Samba, 800 for ADS
• Max No. of User Groups: 64 for Samba, 200 for ADS
• Max No. of Network Shares: Max No. of Network Shares: 128
• User/Group assignment for network sharing/FTP
• Quotas for groups or users
• Assignment of users to multiple groups
• Batch assignment of users to groups
• Batch user creation
• Importing users (CSV Delimited Format)
• Importing groups (CSV Delimited Format)

Backup management

• Remote backups: My Cloud Business Series to My Cloud Business Series locally or remotely
• Apple Time Machine (10.5.8+) support
• Backup internal files or folders of the device to other files/folders on the NAS
• Cloud-based backup services
  • Amazon S3
  • ElephantDrive (http://home.elephantdrive.com/)
• Disk sync management for the attached USB ports

System Management

• LCD display information:
  • IP Address of connected server (and friendly name)
  • Fan monitor
  • System temperature monitor
  • Disk monitor
  • Disk volume monitor
  • Ethernet plug monitor
  • Device uptime
  • Capacity remaining
  • Firmware version
• System status: Device Information
  • Capacity usage status for the external storage
  • File category breakdown of how much video, photo, music is stored
• Alert notifications
  • Event UI message
  • UI Alert (with message acknowledgment required)
  • Email notice
  • QuickView pop-up message
  • RED LED status
• Network recycle
  • Support Windows CIFS
  • Support Apple AFP
• System/FTP Log (Syslog Client)
• HTTP/S (Web) Administration Interface (HTTP Server)
• Firmware upgrade
• Configuration backup and restore
• SNMPv2
• System Information
  • CPU percentage
  • RAM usage
  • Network performance in MB/s

USB port

• Support UPS monitoring
• Support External Storage device
• Support MTP (Media Transfer Protocol) and PTP (Picture Transfer Protocol)

Media Streaming

• UPnP AV Media server (Twonky)
• DLNA certification
• Support WD TV Live, Xbox 360, PlayStation 3, Windows 8, connected TVs, Blu-ray players and digital picture frames
• iTunes Server

Add-on support

• aMule - peer to peer file sharing application
• Icecast - media streaming app
• phpBB - Internet forum application
• Joomla! - content management system
• SqueezeCenter - streaming audio server
• phpMyAdmin - My SQL administration tool
• WordPress - blogging tool and content management system
• Transmission - BitTorrent client

iSCSI

• iSCSI Target
  • CHAP authentication
  • iSNS (Internet Storage Name Service )
  • Up to 64 iSCSI Targets
• Volume Virtualization: NAS can be configured as an iSCSI initiator and capable of mapping any iSCSI target of the other device to be one virtual volume.
  • Virtual Disk Drive (via iSCSI Initiator)
  • Max number of virtual disk drives supported is eight (8)
