Micro MXL Studio 24 USB

CHI TIẾT SẢN PHẨM

Tên thiết bị:  Mic thu âm MXL Studio 24 USB Microphone

Model:   MXL Studio 24

Thương hiệu:  MXL

Tình trạng: đóng hộp, hàng mới, chính hãng 100%

Hình ảnh thiết bị như hình chụp

---

Product Highlights

• 24-Bit USB Microphone
• Compatible with any DAW Software
• Condenser Element
• Cardioid Polar Pattern
• Headphone Output
• Zero Latency Monitoring
• Software Controlled Noise Gate
• Software Controlled Limiter (Leveler)
• Mac & Windows OS



Overview:

MXL Studio 24 USB overview



The Studio 24 USB Microphone from MXL is suited for podcasters, musicians, singers, or anyone in need of a quality microphone for recording audio directly to Windows or Mac OS software. The large diaphragm condenser element features a cardioid polar pattern, and the microphone's USB port is completely plug-&-play and doesn't require any drivers to run.



The Studio 24 USB features latency-free headphone monitoring with its built-in headphone output and level control. The microphone also features software controlled tools such as noise gate, adjustable leveler (limiter), high-pass filter settings, microphone input gain, output level and more. The Studio 24 USB includes a microphone stand, microphone stand mount, USB cable and case.

22mm Condenser Capsule

Gold Sputtered diaphragm

Cardioid Polar pattern

USB bus powered

Zero Latency monitoring with built in Headphone Output

Software based GUI controls analog functions within microphone. Microphone will work without GUI and requires no special drivers.

Supported Bit Depths and Sample Rates: 24-Bit, 48kHz; 24-Bit, 44.1kHz; 16-Bit, 48kHz; 16-Bit, 44.1kHz

Frequency Response: 20Hz to 20kHz

2-stage analog gain control before A/D: Physical rotary and software based with Mute

Signal Phase invert

High pass filter settings: 120Hz, 235Hz, 465Hz

Noise Gate with variable threshold and attack

Leveler with variable Attack, Release, Max & Min Threshold

Output Mixer controls Zero Latency Monitor Level and Mute, Computer Playback Level and Mute, and Master Headphone Level and Mute.

Save/Load feature for quick recall of settings

GUI is Windows (XP/Vista/7) and Mac 10.5/10.6 compatible



Specifications:

MXL Studio 24 USB specs

Analog Performance
Operating Principle	Pressure Gradient
Transducer	Condenser
Polar Pattern	Cardioid
Frequency Range	20 Hz to 20 kHz

Digital Performance
Bit Depth	24-Bit
Sample Rate	44.1 kHz 48 kHz

General
Output Connectors	1 x USB (Type Unspecified)
Headphone Connector	1 x 1/8" (3.5 mm)
Operating Voltage	Not Specified by Manufacturer
Length	6.89" / 175.01 mm
Diameter	1.85" / 46.99 mm
Weight	0.75 lbs / 340 g

Packaging Info
Package Weight	4.25 lb
Box Dimensions (LxWxH)	12.4 x 8.2 x 4.0"



customers also viewed:



In the Box

MXL Studio 24 USB Microphone

• Travel Case
• Microphone Stand
• Microphone Stand Adapter
• USB Cable
• Software CD
• Cleaning Cloth
• Limited 3-Year Warranty
