Micro không dây Shure BLX24A/SM58

CHI TIẾT SẢN PHẨM

Xuất xứ: China (Hàng xịn chính hãng có CO - CQ)

Micro hát karaoke và chuyên nghiệp cao cấp

Bộ thu và phát kèm micro không dây cầm tay BLX24A/SM58





The BLX24/SM58 Handheld Wireless System is part of the BLX wireless systems family.

Includes BLX4 single-channe receiver, BLX2/SM58 handheld transmitter, microphone clip, power supply, 2 AA batteries, and user guide.



I/ Thành phần bộ thiết bị BLX24A/SM58



-  BLX4 Single Channe Receiver

- BLX2/SM58 Handheld Wireless Microphone Transmitter



1/ BLX4 Single Channe Receiver







Đặc tính sản phẩm BLX4

- XLR and ¼" output connectors
- Two-color audio status indicator LED

• Green:  Normal audio levels
• Red:  Excessive audio levels (overload / clipping)


Thông số kĩ thuật BLX4



Output	1x XLR Output 1x 1/4" (6.35 mm) Output
Output Impedance	XLR: 200 ohms 1/4": 50 ohms
Audio Output Level	XLR Connector: -27 dBV into 100 kOhms Load (Reference +/-33 kHz with 1 kHz Tone) 1/4": -13 dBV into 100 kOhms Load (Reference +/-33 kHz with 1 kHz Tone)
RF Sensitivity	-105 dBm for 12 dB SINAD, Typical
Image Rejection	>50 dB, Typical
Housing	Molded ABS
Power Requirement	12 to 15 V DC @ 160 mA, Supplied by External Power Supply (Tip Positive)
Dimensions (H x W x D)	1.5 x 7.4 x 4.1" (40 x 188 x 103 mm)
Weight	8.5 oz (241 g)
Box Dimensions (LxWxH)	13.5 x 12.0 x 3.8"



2/ BLX2/SM58 Handheld Wireless Microphone Transmitter
