Mainboard MSI H310-F Pro

Supports 8th Gen Intel® Core™ processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
2x DDR4 memory slots, support up to 32GB
1x PCIe 3.0 x16 slot
12x PCIe 2.0 x1 slots

PROCESSOR

Supports 8th Gen Intel^® Core™ processors, and Intel^® Pentium^® and Celeron^® processors for Socket LGA1151

See supported processors

CHIPSET

Intel^® H310 Chipset

MEMORY

• 2x DDR4 memory slots, support up to 32GB
• Supports DDR4 2666/ 2400/ 2133 MHz
• Supports non-ECC, un-buffered memory
• Supports Dual-Channel mode
• Supports Intel^® Extreme Memory Profile (XMP)

See supported memory

SLOTS

• 1x PCIe 3.0 x16 slot
• 12x PCIe 2.0 x1 slots

ONBOARD GRAPHICS

• 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
• 1x HDMI^™ port 1.4, supports a maximum resolution of 4096x2160@30Hz

STORAGE

Intel^® H310 Chipset

• 4x SATA 6Gb/s ports

USB

Intel^® H310 Chipset

• 4x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
• 6x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector)

AUDIO

Realtek^® ALC887 Codec

• 7.1-Channel High Definition Audio

LAN

• 1x Intel I219-V Gigabit LAN controller

INTERNAL CONNECTORS

• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 2x 4-pin PCIe power connectors
• 4x 2-pin PS_ON connectors
• 4x SATA 6Gb/s connectors
• 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
• 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
• 1x 4-pin CPU fan connector
• 1x 4-pin system fan connector
• 1x Front panel audio connector
• 2x Front panel connectors
• 1x TPM module connector
• 1x Chassis Intrusion connector
• 1x Serial port connector
• 1x Clear CMOS jumper
• 1x Power button
• 1x Reset button
• 1x Clear CMOS button

BACK PANEL PORTS

1. 4x Debug LEDs
2. 1x PS/2 keyboard/ mouse combo port
3. 1x DVI-D port
4. 1x HDMI port
5. 2x USB 3.1 Gen1 Type-A ports
6. 1x LAN (RJ45) port
7. 2x USB 2.0 port
8. 2x USB 2.0 port
9. 3x Audio Jacks

DIMENSIONS

• 12.0 in. x 8.9 in. (30.5 cm x 22.5 cm)
• ATX Form Factor

MOUNTING

6 mounting holes

OPERATING SYSTEM

Support for Windows^® 10 64-bit

Giá Mainboard MSI H310-F Pro mới nhất

1. Mainboard MSI H310F Pro bán tại Lazada giá 1.238.000₫
