Main ECS H81 H3-A3 Cũ + Chắn lưng Main

CPU Supports New 4th & 4th gen Intel® Core™ family, Pentium, Celeron series processors in LGA1150 socket DMI 5.0GT/s Solid Capacitor for CPU side CHIPSET Intel® H81 Express Chipset GRAPHICS DirectX 11.1 - Only supported with the 4th Gen Intel processors for LGA 1150 socket MEMORY Dual-channelDDR3 Memory architecture Supports 1600/1333/1066 non-ECC, Un-buffered SDRAM Memory 2 X 240-pin DDR3 DIMM socket Support up to 16 GB* EXPANSION SLOT 2 X PCI Express X16 Gen 2.0 slot(s) 2 X PCI Express X 1 Gen 2.0slot(s) Supports AMD CrossFire™ Technology 2 X PCI slot(s) *The second PCIE X16 only support bandwidth X 1 STORAGE Support by Intel® H81 Express Chipset 2 X Serial ATAIII 6Gb/s 2 X Serial ATAII 3Gb/s AUDIO Realtek ALC662 ‧Realtek ALC662 6-channel High Definition audio CODEC ‧Meets performance requirements for Microsoft WLP 3.08 Vista premium and mobile PCs ‧Six channel DAC supports 16/20/24-bit PCM format for 5.1 channel audio solution ‧Emulation of 26 sound environments to enhance gaming experience ‧Voice Cancellation and Key Shifting in Karaoke mode ‧Compatible with Direct Sound 3D™, A3D™, I3DL2 LAN Realtek 8111G Gigabit Fast Ethernet Controller Wake-On-LAN USB Support by H81 Express Chipset 2 X USB3.1 Gen1 port(s) up to 5Gb/s 8 X USB2.0 port(s) Up to 480 Mb/s REAR PANEL I/O 1 X PS/2 Keyboard & PS/2 mouse connectors 1 X Audio port (Line Out/Line In/Mic In) 1 X RJ-45 port 1 X DVI-D port(s) 2 X USB3.1 Gen1 port(s) 4 X USB2.0 port(s) CONNECTORS & HEADERS 1 X 24-pin ATX Power Supply connector 1 X 4-pin 12V Power connector 1 X 4-pin CPU_FAN connector 1 X 4-pin SYS_FAN connector 1 X 3-pin NB_FAN connector 1 X 3-pin PWR_FAN connector 1 X Speaker header 2 X USB 2.0 header Support additional 4 USB ports 2 X SATA III 6Gb/s connector(s) 2 X SATA II 3Gb/s connector(s) 1 X CLR_CMOS header 1 X Serial port header (COM) 1 X Parallel port header (LPT) SYSTEM BIOS AMI BIOS with 64 MB SPI Flash ROM Supports M.I.B III Utility ACPI & DMI F7 hot key for boot up devices option Graphic OC Support Dual Display Support ECS EZ BIOS Plug and Play, STR (S3) / STD (S4) , Hardware monitor, Multi Boot Multi-Language BIOS Audio, LAN, can be disabled in BIOS Supports PgUp clear CMOS Hotkey FORM FACTOR ATX Form Factor 305mmX190mm OS SUPPORT Windows 7 32-bit Windows 7 64-bit Windows 8 64-bit
