1. Supply voltage 3.2V - 5.5V. (If you want to work in the module launch state for a long time, it is recommended when the supply voltage exceeds 4.5V series with a 1N4007 diode, to avoid heating module built LDO)
2. Default communication distance (open test): about 600m (adjustable to achieve the maximum communication distance of 1000m, the air baud rate 5000bps).
3. The default idle current: 16MA (modules in different operating current of the different operating modes).
4. Operating frequency range: 433-473.0MHz, up to 100 communication channels. Maximum 100mW transmit power (can be set)
5. The module supports software upgrades. The default factory settings: operating mode FU3, baud rate 9600bps, communication channel CH001 (433M).
colour:Blue
Material:plastic
size:27.8 x 14.4 x 4mm
Package Contents:
1 x Wireless Serial Port Module
2. Default communication distance (open test): about 600m (adjustable to achieve the maximum communication distance of 1000m, the air baud rate 5000bps).
3. The default idle current: 16MA (modules in different operating current of the different operating modes).
4. Operating frequency range: 433-473.0MHz, up to 100 communication channels. Maximum 100mW transmit power (can be set)
5. The module supports software upgrades. The default factory settings: operating mode FU3, baud rate 9600bps, communication channel CH001 (433M).
colour:Blue
Material:plastic
size:27.8 x 14.4 x 4mm
Package Contents:
1 x Wireless Serial Port Module
|
