Đồng hồ vặn năng- Kyoritsu 2012RA

Hãng sản xuất: Kyoritsu – Nhật Model: 2012RA Xuất xứ: Thailand Bảo hành : 12 tháng MÔ TẢ DC V 600.0mV/6.000/60.00/600.0V (Input impedance: approx. 10MΩ) ±1.0%rdg±3dgt AC V 6.000/60.00/600.0V (Input impedance: approx.10MΩ) ±1.5%rdg±5dgt (45 – 400Hz) DC A 60.00/120.0A ±2.0%rdg±8dgt (60A) ±2.0%rdg±5dgt (120A) AC A 60.00/120.0A ±2.0%rdg±5dgt (45 – 65Hz) Ω 600.0Ω/6.000/60.00/600.0kΩ/6.000/60.00MΩ ±1.0%rdg±5dgt (600Ω/6/60/600kΩ) ±2.0%rdg±5dgt (6MΩ) ±3.0%rdg±5dgt (60MΩ) CONTINUITY BUZZER Buzzer sounds below 35±25Ω DIODE TEST 2V±3.0%rdg±5dgtOpen-loop voltage: approx. 2.7V CAPACITANCE 400.0nF/4.000/40.00µF ±2.5%rdg±10dgt FREQUENCY (AC A) 100/400Hz ±0.2%rdg±2dgt (100Hz) ±0.1%rdg±1dgt (400Hz) (DC A) 100/1000Hz/10/100/300.0kHz ±0.2%rdg±2dgt (100Hz) ±0.1%rdg±1dgt (1000Hz/10/100/300.0kHz) (Input sensitivity Current: more than 6A Voltage: more than 6V [- 10kHz]/more than 20V [10k – 300kHz]) CONDUCTOR SIZE Ø12mm max. APPLICABLE STANDARDS IEC 61010-1 CAT III 300V, CAT II 600V Pollution degree 2 IEC 61010-031, IEC 61010-2-032, IEC 61326 POWER SOURCE R03 (1.5V) × 2 * Continuous measuring time: DCV: approx. 150hours, ACA: approx. 25hours (Auto power save: approx. 15 minutes) DIMENSIONS 128 (L) × 92 (W) × 27 (D) mm WEIGHT 220g approx. (including batteries) INCLUDED ACCESSORIES R03 (1.5V) × 2, Instruction manual OPTIONAL ACCESSORIES 9107 (Carrying case [Soft])
