Đồng hồ đo Ampe Kế DC 10A bp-80

Đồng hồ đo ampe-10A BP-80 THÔNG SỐ KỸ THUẬT: NAME SPECIFICATION ACCURACY AC AMMETER FROM 10A, 15A, 20A, 30A...TO 3000A, 5000A WITH EXT. C/T 1A OR 5A CLASS 1.5 FROM 0.1A, 0.5A, 1A, 5A, 10A, 25A...TO 80A, 100A AC DIRECT CONNECTION CLASS 1.5 DC AMMETER FROM 50uA, 100uA, 1mA, 5mA...1A, 5A, 10A, 25A, 30A...TO 100A DC DIRECT CONNECTION CLASS 1.5 FROM 10A, 15A, 20A, 30A...2500A, 3000A...TO 8KA, 10KA WITH EXT. SHUNT 50MV, 60MV OR 75MV CLASS 1.5 AC VOLTMETER FROM 30V, 50V, 100V...TO 300V, 500V, 600V AC DIRECT CONNECTION CLASS 1.5 FROM 1KV, 2KV, 5KV...TO 380KV, 450KV WITH EXT. VOLTAGE TRANSFORMER CLASS 1.5 DC VOLTMETER FROM 10V, 20V, 30V...TO 500V, 600V, 1000V DC DIRECT CONNECTION CLASS 1.5 FROM 1KV, 2KV, 5KV...TO 8KV, 9KV, 10KV WITH EXT. RESISTOR CLASS 1.5 FREQUENCY METER VOLTAGE: 110V, 220V, 380V, 440V ....... CLASS 1.0 FREQUENCY: 45-55Hz, 45-65Hz, 55-65Hz, 47-53Hz POWER FACTOR METER (COS ) VOLTAGE: 110V, 220V, 380V, 440V CURRENT: 1A OR 5A FOR 1PHASE OR 3PHASE CLASS 2.5 FULL SCALE VALUE: 0.5cap-1-0.5ind, 0.3cap-1-0.1ind, 0.7cap-1-0.2ind POWER METER (KW OR KVAR) VOLTAGE: 110V, 220V, 380V, 440V CURRENT: 1A OR 5A FOR 1P1W, 3P3W, 3P4W CLASS 1.5 WITH C/T OR VOLTAGE TRANSFORMER
