Small form factor
easy to use
easy to use
Powerful
Wide range of applications
Product parameters:
Working voltage: DC4.5V-35V
Output current: 0-5A
Output power: 90W (maximum)
Quiescent current: 7uA (standby)
PWM duty cycle: 1%-100%
PWM frequency: 20khz
Dimensions: 30mm x 26mm x 14mm (without handle)
Precautions
The input of the DC motor speed controller is DC, it cannot be directly connected to AC (for example: 220V AC 220V), otherwise it will burn!
The positive and negative terminals of the DC power supply are not reversed, otherwise the governor may be damaged.
The motor can be positive or negative. When the operation direction does not match the expectation, you can adjust the line sequence to change the direction.
Adjust the potentiometer knob to change the output duty cycle of the governor, and the motor speed changes.
Package Included
1 x 5V-35V speed control switch
