Camera IP VStarcam C7816WIP



System	Operation system	Embedded Linux OS
	Online visitor	Support 4 visitors at the same time
Image Capture	Image sensor	1/4 inch 720p Progressive Scan CMOS
	Minimum Illumination	0.3~0.5 Lux (Color mode), 0 Lux（B&W mode）
	Lens	[email protected]
	View Angle	71.1°（diagonal）
	Night vision	Dual Filter,IR-Cut，2pcs 850nm Φ28mil high power IR LED； IR irradiation distance:8~15m
Video	Encode format	H.264 main profile@level:4.0/Motion-JPEG/JPEG
	Three Stream	Main Stream:720p(1280X720)@25fps Sub Stream:360p(640X360)@25fps Third Stream:180p(320X180)@10fps
	Bit Rate	128～4096kbps
	Maximum frame rate	25fps
	Image adjustment	Contrast、Brightness、Saturation、Hue
Audio	N/A	/
Network	Ethernet	10Base-T / 100Base-TX, RJ45 connector
	Protocols	TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc
	Wireless LAN	IEEE802.11b/g/n
	Wireless LAN Frequency	2.4~ 2.4835GHz
	Wireless LAN security	64/128-bit WEP/WPA-PSK /WPA2-PSK data encryption
Pan-tilt	N/A	/
Memory	Socket	TF Push-push socket,Maximum support 128GB
Alarm	Alarm Trigger	Motion detection
Physical Environmental	Rated voltage	DC12V±5%
	Power consumption	Related power:6W(IR LED turn on)
	Operating condition	Temperature:-10～50℃,humidity:＜90%
	Weight	Gross：335g(Note: in kind prevail)
	Package size	176*166*110mm(L×W×H)
