Bo Mạch Chủ MSI B360 A Pro

*PROCESSOR Supports 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors for Socket LGA1151 *CHIPSET Intel® B360 Chipset *MEMORY 4 x DDR4 memory slots, support up to 64GB Supports DDR4 2666/ 2400/ 2133 MHz1 *Dual channel memory architecture Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) Please refer to Compatibility for more information on compatible memory *SLOTS 2 x PCIe 3.0 x16 slots (supports x16/ x4 mode) 4 x PCIe 3.0 x1 slots *ONBOARD GRAPHICS 1 x DisplayPort 1.2, supports a maximum resolution of 4096x2304 @ 60Hz 1 x DVI-D port, supports a maximum resolution of 1920x1200 @ 60Hz *MULTI-GPU Supports 2-Way AMD® CrossFire™ Technology *STORAGE Intel® B360 Chipset 5 x SATA 6Gb/s ports1 1 x M.2 slot (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices2 Intel® Optane™ Memory Ready SATA1 port will be unavailable when an M.2 SATA SSD module has been installed in the M.2 slot. Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. USB Intel® B360 Chipset 2 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel) 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connector) 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors) AUDIO Realtek® ALC892 Codec 7.1-Channel High Definition Audio LAN 1 x Intel® I219-V Gigabit LAN controller INTERNAL CONNECTORS 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 6-pin ATX PCIe power connector 5 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin water pump fan connector 5 x 4-pin system fan connectors 1 x Front panel audio connector 2 x Front panel connectors 1 x Series port connector 1 x Parallel port connector 1 x TPM module connector 1 x Thunderbolt Add-on Card Connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper BACK PANEL PORTS PS/2 Combo Port DVI-D Port DisplayPort USB 3.1 Gen2 Type A LAN Port HD Audio Connectors USB 2.0 Port USB 3.1 Gen2 Type C USB 3.1 Gen1 MSI B360-A PRO back panel ports DIMENSIONS 12 in. x 9.6 in. (30.4 cm x 24.3 cm) ATX Form Factor MOUNTING ------------------------------------------ THÔNG TIN LIÊN HỆ : Công Ty TNHH Quyền Linh Tech -Địa chỉ : 108 đường Bưởi, P. Ngọc Khánh, Q. Ba Đình, TP. Hà Nội -Hotline : 0988 279 858 / Zalo : 0988 279 858 -Website : quyenlinhtech.vn -Email : [email protected] -Group: http://fb.com/quyenlinhtech/ -Kênh Youtube : http://bit.ly/QuyenLinhTechYoutube #main #bomachchu #bomạchchủ #mainpc #mainbomạchchủ #mainmáytính #mainmsi
