Bo Mạch Chủ-Mainboard MSI B450M BAZOOKA PLUS

Bo Mạch Chủ - Mainboard MSI B450M BAZOOKA PLUS PROCESSOR Support AMD® Ryzen™ 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics Processors for Socket AM4 CHIPSET AMD® B450 Chipset MEMORY 4 x DDR4 memory slots, support up to 64GB Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC) Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3333 MHz (by A-XMP OC MODE) Supports Dual-Channel mode Supports non-ECC UDIMM memory Supports ECC UDIMM memory SLOTS 1x PCIe 3.0 x16 slot Supports x16 speed with AMD® Ryzen™ 1st and 2nd Generation processors Supports x8 speed with AMD® Ryzen™ with Radeon Vega Graphics processors 2x PCIe 2.0 x1 slots ONBOARD GRAPHICS 1x DVI-D port, support a maximum resolution of 1920x1200@60Hz1 1x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz1 Only support when using AMD® Ryzen™ with Radeon Vega Graphics Processors Maximum shared memory of 2048 MB STORAGE AMD® B450 Chipset 4 x SATA 6Gb/s ports AMD® CPU 1 x M.2 slot (M2_1, Key M) Supports PCIe 3.0 x4 and SATA 6Gb/s 2242/ 2260 /2280/ 22110 storage devices RAID AMD® B450 Chipset Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices USB AMD® B450 Chipset 8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB 3.1 Gen1 connectors) 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors) AUDIO Realtek® ALC892 Codec 7.1-Channel High Definition Audio LAN 1 x Realtek® RTL8111H Gigabit LAN controller INTERNAL CONNECTORS 1 x 24-pin ATX 12V power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (support additional 4 USB 2.0 ports) 2 x USB 3.1 Gen1 connectors (support additional 4 USB 3.1 Gen1 ports) 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 2 x 5050 RGB LED strip 12V connectors 1 x TPM module connector 1 x Front panel audio connector 2 x System panel connectors 1 x Chassis Intrusion connector 1 x Clear CMOS jumper 1 x Serial Port connector 1 x Parallel Port connector BACK PANEL PORTS DVI-D Port PS/2 Combo Port USB 3.1 Gen1 LAN Port HDMI Port BIOS FLASHBACK+ Button USB 2.0 Port HD Audio Connectors MSI B450M BAZOOKA PLUS back panel ports DIMENSIONS 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) M-ATX Form Factor MOUNTING 8 mounting holes OPERATING SYSTEM Support for Windows® 10 64-bit Support for Windows® 7 64-bit * To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
