CHI TIẾT SẢN PHẨM

Mainboard Asus TUF B350M-PLUS GAMING

Mainboard Asus TUF B350M-PLUS GAMING

THÔNG SỐ KỸ THUẬT

• Hãng sản xuất: Asus
• Model: TUF B350M-PLUS GAMING
• CPU: AMD AM4 Socket AMD Ryzen™ 2nd Generation/Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics/Ryzen™ 1st Generation/7^th Generation A-series/Athlon X4 Processors. Supports CPU up to 8 cores
• Chipset: AMD B350
• Bộ nhớ: AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors
  - 4 x DIMM, Max. 64GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
  AMD 7th Generation A-Series/Athlon X4 Processors
  - 4 x DIMM, Max. 64GB, DDR4 2400/2133 MHz Un-buffered Memory
  - Dual-Channel Memory Architecture
  - ECC Memory (ECC mode) support varies by CPU.
• Graphic: Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ 7th Generation A-Series APU
  Multi-VGA output support : HDMI/DVI/RGB ports
  - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 2048 MB (for iGPU exclusively)
• Multi-GPU: Supports AMD CrossFireX™ Technology
• Khe cắm mở rộng: AMD Ryzen™ 2nd Generation/ Ryzen™ 1st Generation Processors
  - 1 x PCIe 3.0/2.0 x16 (x16 mode)
  AMD Ryzen™ with Radeon™ Vega Graphics /7th Generation A-Series/Athlon X4 Processors
  - 1 x PCIe 3.0/2.0 x16 (x8 mode)
  AMD Athlon™ with Radeon™ Vega Graphics Processors
  - 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
  AMD B350 chipset
  - 2 x PCIe 2.0 x1 (max at x4 mode)
  - 1 x PCIe x1
• Lưu trữ: AMD B350 chipset : 4 x SATA 6Gb/s port(s), gray, Support Raid0, 1, 10
  AMD Ryzen 2nd Generation/ Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics/ Ryzen 1st Generation/ 7th Generation A-Series/ Athlon X4 Processors : 2 x SATA 6Gb/s port(s), gray
  AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
  - 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*¹
  AMD 7th Generation A-Series/Athlon X4 Processors :
  - 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)*²
  AMD Athlon™ with Radeon™ Vega Graphics Processors :
  - 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA mode)
• LAN: Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
• Âm thanh: Realtek® ALC887 8-Channel High Definition Audio CODEC
• Cổng USB: AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/ 7th Generation A-Series/ Athlon™ X4 Processors :
  - 4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
  AMD B350 chipset :
  - 2 x USB 3.1 Gen 2 port(s) (2 at back panel, teal blue)
  AMD B350 chipset :
  - 2 x USB 3.1 Gen 1 port(s) (2 at mid-board)
  AMD B350 chipset :
  - 6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)
• Kích thước: mATX Form Factor
  9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
• Bảo hành: 36 tháng
