Bo mạch chủ ASUS E3 PRO GAMING V5

Mainboard ASUS E3 PRO GAMING V5_ hàng bóc máy dùng tốt Hãng sản xuất Asus Chủng loại Asus E3 Pro Gaming V5 CPU hỗ trợ Intel® Socket 1151 for Xeon® E3_1200 v5 and 6th genereation CoreTM, Pentium® and Celeron® Processors Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. * Refer tofor CPU support list Chipset Intel® C232 Bộ nhớ trong 4 x DIMM, Max. 64GB, DDR4 2133 MHz ECC, Non_ECC, Un_buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) VGA onboard n/a Âm thanh SupremeFX 8_Channel High Definition Audio CODEC _ Supports : Jack_detection, Multi_streaming, Front Panel MIC Jack_retasking _ High quality 115 dB SNR stereo playback output Audio Feature : _ SupremeFX Shielding™ Technology _ Optical S/PDIF out port(s) at back panel _ Sonic Radar II Khe mở rộng 1 x PCIe 3.0/2.0 x16 (x16 mode, ) 1 x PCIe 3.0/2.0 x16 (max at x4 mode) *1 2 x PCIe 3.0/2.0 x1 2 x PCI Chuẩn lưu trữ Intel® C232 chipset : 1 x M.2 Socket 3, with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD)*2 6 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10 Intel® Rapid Storage Technology Enterprise supports*3 Cổng giao tiếp trước và sau 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x LAN (RJ45) port(s) 1 x USB 3.1 (red)Type_A 1 x USB 3.1 Type_C 4 x USB 3.0 2 x USB 2.0 1 x Optical S/PDIF out 5 x Audio jack(s) Công nghệ tích hợp Gamer's Guardian: _ ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports _ DRAM Overcurrent Protection _ Stainless Steel Back I/O _ Highly Durable Components _ DIGI+ VRM ASUS EPU : _ EPU ASUS Exclusive Features : _ Ai Charger+ _ ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface _ USB 3.1 Boost _ Disk Unlocker ASUS Quiet Thermal Solution : _ Stylish Fanless Design Heat_sink solution _ ASUS Fan Xpert 3 ASUS EZ DIY : _ ASUS CrashFree BIOS 3 _ ASUS EZ Flash 3 _ ASUS UEFI BIOS EZ Mode _ Push Notice ASUS Q_Design : _ ASUS Q_Shield _ ASUS Q_LED (CPU, DRAM, Boot Device LED) _ ASUS Q_Slot _ ASUS Q_DIMM Media Streamer RAMCache Kích thước ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) Phụ kiện đi kèm User's manual I/O Shield 4 x SATA 6Gb/s cable(s) 1 x M.2 Screw Package 1 x pack of cable tie 1 x Supporting DVD 1 x 12 in 1 Cable Label (s)
