5V-30V Micro USB Power Adjustable Delay Relay Timer Control Module Trigger Delay Switch

Wide voltage 5V-30V trigger delay relay module timer module delay conduction delay switchModule highlights:The time can be adjusted by the potentiometer to meet your most occasions.With MicroUSB 5.0V power input, it is very convenient to use.5--30V ultra-wide power supply voltage.There are two trigger modes: external trigger and onboard button.With relay pull-in indicator light.Strong anti-interference ability, the relay will not malfunction under various interferences, suitable for industrial control.1. The anti- theft alarm delay, building sound and light control lamp switch.2. The vehicle -mounted device is turned on delay, to prevent excessive current when the car ignition burned - board equipment.3. The need to have in order to start the case, to prevent multiple devices simultaneously starting current is too large burning appliances.Module features:1. Working voltage: any voltage between wide voltage 5--30V, MicroUSB and welding terminal two power supply interfaces2. Working mode: After supplying power to the module, the status of the output terminal of the module is: normally open (NO) disconnected from the common terminal (COM), and normally closed (NC) connected to the common terminal (COM). Give a low pulse signal at the external trigger terminal (TRIG), or at the moment when the trigger button is touched, the relay is activated and the work indicator light is on. At this time, the status of the relay output terminal is normally open (NO) and the common terminal (COM) is conducting. Closed (NC) and common (COM) are disconnected. After 0-24 seconds (this time can be adjusted according to your needs), the relay is disconnected, and the relay returns to the state before triggering.3. The time can be adjusted by the potentiometer, the default is 0-24 seconds. If it takes longer, you can replace a larger capacitor (C2) or potentiometer yourself. Delay time formula: T=1.1RC. For example: capacitor 22uf resistance 1M, then T=1 .1*0.000022*1000000=24.2 seconds.4. With a relay pull-in indicator.5. The module can control: after 10A 250VAC (AC), the load is below 10A 30VDC (DC).6. With relay freewheeling protection.7. The signal end of the module is designed with pull-up and filter circuit, which has strong anti-interference ability and is suitable for industrial control. Many manufacturers have added optocouplers for isolation, but the module is not isolated from the ground of the trigger signal, and it is not effective in anti-interference. After testing, it is found that the stability of the trigger terminal must be improved to resist interference. The relay will not malfunction regardless of whether it is in an electromagnetic interference environment or the moment the module is powered on or off.8.Size: 5.4*1.9*1.8cm (length*width*height)
