3CH DC12-24V RGBW DMX 512 Decoder LED Controller RGB LED DMX512 Decoder, DMX512-3CH

The receiving standard DMX512 (1990) signal, and the channel value is converted to LED brightness value.Three - channel occupied DMX512, through three channels to achieve color mixing effect.It has two working modes, DMX mode and built-in operation mode.DMX signal interface - with two kinds of standards: XLR-3 and RJ45 interface.The DMX address code can be set by dip switch.It has 16 built-in modes and 32 speed grade.The output using standard green plug terminals, with mounting holes, easy to install.Input voltage: DC12~24VMaximum output power: 60W 144W~ 288WDimming mode: PWMAddress range: 1~511Operating temperature: -20-60℃Protect level: IP20colour: blackMaterial: plasticPackage Contents:1 x 3CH DMX512 Decoder2 x Canon plug
