3.5 inch LCD Display HDMI compatible 3.5" HD LCD Touch Screen Display Module 480×320 1920x1080 Support Systems for Raspberry Pi

Brand Name:Your Cee
Origin:CN(Origin)
Display Mode:480x320 1920x1080
Model Number:3.5 inch LCD Display HDMI-compatible
is_customized:Yes
Type:Standard
Resolution:128*64

3.5inch standard display, support HDMI input, refresh rate above 60FPS

Physical resolution 480x320, configurable software resolution up to 1920x1080

It is compatible with mainstream mini PC such as Raspberry Pi, BB Black, Banana Pi

It can also be used as a general-purpose HDMI display, connecting computers, TV boxes, Microsoft Xbox360, SONY PS4, Nintendo Switch and so on

Used as a Raspberry Pi display that supports Raspbian, Ubuntu, Kodi, Win10 IOT, single-touch, free drive

Work as a PC monitor, support Win7, Win8, Win10 system (No touch Function)

Support HDMI audio output,Backlight brightness can be adjusted

Parameters

Size: 3.5(inch)

SKU: MPI3508

Physical Resolution: 480×320(dots)

Software adjustable resolution: 480×320~ 1920×1080(dots)

Touch: Resistance Touch

Power Dissipation: 0.20A*5V (Brightness @100%)/0.15A*5V (Backlight close)

1.Backlight button: backlight brightness adjustment button, short press backlight changes by 10%, long press 3 seconds to close backlight

2.HDMI interface: HDMI signal input interface

3.Amplifier interface: HDMI audio output interface

4.USB power supply interface: provide power for ordinary display (5V 1A)

5.Transaction raspberry pie 26PIN base: gets power and return touch from this area when used as a raspberry pie monitor
