Shockley WZ10020L 100V 1000W Điện Áp Cao Công Suất Cao Dc Bước Xuống Điện Áp Không Đổi Dòng Không Đổi Mppt Pin Năng Lượng Mặt Trời Bộ Cấp Nguồn Sạc

Product selling point

1: Widely used

2: Multiple working modes are available

3: Increase the heat sink, install intelligent fan, enhance heat dissipation, reserve another fan 5V interface, convenient to add fans, enhance heat dissipation.

4: Adopt synchronous rectification technology, high conversion efficiency

5: Has multiple software protection mechanisms, and the protection threshold can be set and adjusted. When the working parameters of the module exceed the protection threshold, the output is automatically shut down

1. Baby highlights:

1.1 Multiple working modes are available:

1. Working mode of DCDC power supply and battery charging.

2.MPPT solar charging mode.

1.2 Output special charging interface:

1. Physical isolation of relay to prevent reverse inverting, safer charging. 2. Intelligent switching of multiple charging modes.

3. Automatically turn off when fully charged and the input voltage power is insufficient, and automatically recover when the battery voltage is insufficient or the input power supply rises.

4. Over temperature, over power, over voltage, over current protection off.

5. Automatic shutdown with fixed time and fixed capacity.

6. MPPT solar charging, maximum power automatic tracking, improve charging efficiency.

1.3 A variety of interface display: LCD can display input voltage/output voltage/temperature, output current/output power/output capacity/output time;

1.4 NC constant voltage constant current adjustment, accurate and fast, step-down output, output voltage 0-100.00V arbitrary adjustment. When the voltage output is set less than 50V, the limited current 0-20.00A can be adjusted arbitrarily; When the voltage output is set to more than 50V, the limited current 0-10.00A can be adjusted arbitrarily.

1.5 The module can be enabled or disabled by default, and the power-off parameters can be saved.

1.6 Multiple software protection mechanisms are provided, and the protection thresholds can be set and adjusted. When the working parameters of the module exceed the protection threshold, the output will be automatically closed.

1.7 Synchronous rectification technology is adopted, with high conversion efficiency.

1.8 Increasing the heat sink: Smart fans are installed to enhance heat dissipation. Another 5V port is reserved for connecting to the fan to facilitate adding fans to enhance heat dissipation.

1.9 TTL serial port and input control IO are reserved for customizing.

2: Product parameters

Input voltage range: 10-110.00V

Input voltage resolution: 0.01V

Output voltage range: 0-100.00V (step-down)

Output voltage resolution: 0.01V

Output current range:

0-20.00A (Output 0-50V)

0-10.00A (Output 50-100V)

Output current resolution: 0.01A

Output power range: 0-1000W

Input voltage accuracy: ±(1%+5 words)

Output voltage accuracy: ±(0.3%+5 words)

Output current accuracy: ±(0.5%+5 words)

Typical value of output ripple: 300mV peak-peak value

Normal operating temperature range: -20℃~50℃

Capacity measurement range: 0-999.9AH

Capacity energy statistical error: ±2%

Statistical time range: 0 to 100 hours

Depressurization operation mode:

Pressure difference > input voltage X0.05%+1V

Net weight: about 285g

Including packaging weight: about 340g

Product size: Panel size: 79*43*25mm

Motherboard size: 130*90*40mm

Soft boot: Yes

Protection mechanism:

Input undervoltage protection (adjustable from 9-110V, default is 9V)

Output overvoltage protection (adjustable 0-101.0V, default 101.0V)

Output overcurrent protection (adjustable from 0 to 20.10A, default 20.10A)

Output overpower protection (adjustable from 0 to 1010W, default 1010W)

Overtemperature protection (adjustable from 80-110℃, default 110℃)

Timeout protection (adjustable from 0 to 100h, off by default)

Overcapacity protection (adjustable from 0 to 999.9Ah, disabled by default)

list

1* Power module
