Nhiệt kế tự ghi Elitech RC-4 (cảm biến nhiệt độ rời)

Elitech RC-4H thermometer data logger

This data logger is mainly used for temperature recording during storage and transportation of foodstuff, medicine, chemicals and other products, especially widely used in all links of warehousing, logistics and cold chain, such as refrigerated containers, refrigerated trucks, refrigerated package, cold storage, laboratory, etc.



Technical Parameters:



This data logger is mainly used for temperature recording during storage and transportation of foodstuff, medicine, chemicals and other products, especially widely used in all links of warehousing, logistics and cold chain, such as refrigerated containers, refrigerated trucks, refrigerated package, cold storage, laboratory, etc.



Technical Parameters:



Feature:
-This data logger is mainly used for temperature and humidity recording during storage and transportation of foodstuff, medicine, chemicals and other products, especially widely used in all links of warehousing, logistics and cold chain, such as refrigerated containers, refrigerated trucks, refrigerated package, cold storage, laboratory, etc.
- It has a large permanent data memory of 16000 points and comes with data management software for easy data download to computers through USB interface. With the software, you could analyze data in form of tables and graphs and export in picture format. The data could be queried, saved, printed and exported in Word/Excel/TXT format.
- Wide measuring range, high accuracy for Temperature and Humidity. Temperature measuring range: -30 C to +60 C; Humidity measuring range: 0 to 99%RH.
- Data management software & USB cable included for working with PC easily
- Data can be downloaded, analyzed, exported and printed conveniently
- Over Temperature Alarm & Upper/Lower Limits can be set
- MAX/MIN values available

Specificaton:
  - Temperature measuring range:  -30 Celsius ~+60 Celsius;external sensor(cable length 1.1m), -40 Celsius~+85 Celsius;

-Temperature accuracy: -30 Celsius~+60 Celsius, ±0.6 Celsius;others, ±1.2 Celsius;

- Temperature unit: C or F optional, set through RC-4H data management software.
- Humidity measuring range: 0~99%RH
- Humidity accuracy: ±3%RH(25 Celsius,20~90%RH),others,±5%RH;

-Resolution: Temperature 0.1 Celsius;Humidity 0.1%RH;

- Record capacity:  RC-4HC 16000points(MAX)
- Record interval: 10s~24hour adjustable;
- Communication interface: USB interface;
-2 kinds of Power supply: inner CR2450 battery or power supply via USB interface;
- Battery life: in normal temperature, if the record interval sets as 15 minutes, it could be used above one year.
- Ambient environmental temperature: -30 Celsius~+60 Celsius;in the low temperature environment, LCD displays slowly, while it has not an impact on the normal measuring nor recording. Once the temperature recovers, it could display normally.

-The data logger display interfaces includes: temperature status display, humidity status display, record capacity display, time display, date display, Max. temperature display, Min. temperature display, Max. humidity display, Min. humidity display.
- Product size: 84mm (length) X 44mm (width) X 20 mm (height)
-Logger weight: 40g

Package include
-1*Temperature logger(battery included)
-1*External Sensor
-1*usb cable
-1*user manual
