Ministar Rơ Le Trễ NE555 DC 12V Công Tắc Hẹn Giờ Mô-đun Điều Chỉnh Được

Description:



100% Brand new and high quality

This is a brand new and high quality delay turn-on module.

The use of high-performance timing CPU design.

The power indicator LED and switch trigger timing indication

LEDs;

The output can be connected to AC 250V 10A DC 30V 10A

Load;

There is the chronopotentiometry regulation time, adjustable

From0 to 10 seconds by default, or by changing the

Capacitance adjustment time longer.

Applications of use:

Vehicle equipment-delay to prevent car ignition, prevention of

High sudden current to burn out components and devices.









Specification:

1.Module based on: NE555 chip.

2. Delay module: delay connect module

3. Input voltage: DC12V

4. Control voltage: AC 0~250V / max. 10A, DC 0~30V / max. 10A the operating voltage: 12 volts DC; (otherwise 5V optional)

5. Max. Load: 2200W



Main Chip (NE555) Characteristics:

1. Timing from microseconds to long hours

2. Simple circuit design

3. Precision Pulse Generation / Timing.

4. Adjustable Duty Cycle

5. Countless Application and Information Sources









Package Included: 1pcs Channel Relay Timer









Note:Due to manual measurement,please allow an error of 1-3mm.
