KKmol Single Channel/4 Channel 18650 Dung lượng pin Đầu dò điện trở trong Bộ sạc và xả tự động Loại cổng c Đo sạc và xả 1~9 chu kỳ Điều chỉnh sạc và xả

Single channel:

About power-off storage:

This product has no power-off storage function. Shutting down, restarting, and switching the working mode can cause the accumulated data to be cleared (as shown below).

01

It can be used well

The working mode corresponds to the state change

Product name: 18650 battery capacity internal resistance tester charging and discharging integrated version

Working voltage: DC5V

Detection voltage: ≤DC5V

Capacity measurement range: 0~99999mAh

Energy measurement range: 0~99999mWh

Battery internal resistance measurement: support, measurement error is about 10%

Display real-time voltage: support

Display real-time current: support

Display real-time power: support

Log run time: support

Working mode indication: support

Current Status Indication: Supported

Simultaneous discharge: not supported (simultaneous discharge of 18650 battery Test① and external power supply Test② is not supported)

Discharge load: 10W 8ΩJ cement resistance × 2

Discharge current selection: ≈0.5A or ≈1A

Charging interface: Type-C

External discharge interface: Type-C

Preset discharge stop voltage: 3V (not adjustable)

Preset full stop voltage: 4.2V (not adjustable)

Data storage: The measurement data is not saved, and the accumulated data is automatically cleared when the power is turned off or when the working mode is switched.

Product size: 108×85×24mm

Product weight: 80g (net weight)

Package includes:

1*18650 battery capacity internal resistance detector automatic charging and discharging module

4 channel:

Basic parameters

Working voltage: DC5V

Applicable battery: suitable for all batteries that meet the requirements of stopping discharge voltage of 2.5~3.5V and starting from 2.8V to 4.2V

Power supply interface: Two-way Type-C power supply interface (power supply and power cord are provided)

System language: English/Chinese can be switched

Test quantity: 4-way charging and discharging measurement

Internal resistance measurement: support, use DC two-wire method to test internal resistance

Charging function: support, automatic cut-off charging when fully charged (lithium iron phosphate battery charging is not supported)

Discharge function: support, automatically stop when conditions are met, and the discharge current is not adjustable

Automatic charging and discharging: supported. The battery is fully charged at the end of automatic mode

Cyclic charging and discharging: supported, 1~9 cycles adjustable (only supported in automatic mode)

Status prompt: Supported

Cooling mode: fan active cooling

Overheat protection: support

Stop discharge voltage: 2.5V, 2.6V, 2.7V, 2.8V, 2.9V, 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5V, 11 adjustable gears

Discharge current: the maximum current is about 1A, which is not adjustable, and does not support independent transformation

Charging voltage: controlled by a special battery charging chip, with a maximum charge of about 1A and a full charge voltage of 4.2V

Power-off saving: only save the set parameters, not the measurement data

Product size: 150 × one hundred and three × 36mm

Package size: 182 × one hundred and twelve × 50mm

Data link: https://www.banber.com/gather/6374be9b2ee0e200077ec155
