Kebidumei Bo Mạch Giải Mã MP3 MP4 MP5 Bluetooth Không Dây Mô-đun Giải Mã Video Âm Thanh Hỗ Trợ Đĩa TF/ U Đài FM Giắc Cắm Aux 3.5Mm Cho Loa Máy Phát Đa Phương Tiện Máy Chiếu Có Điều Khiển Từ Xa

Note:

1. The product does not come with a power amplifier board and cannot be directly connected to the audio. If you need to connect the audio directly, you can purchase a matching power amplifier board.
2. The maximum operating voltage of the product is 12V, and the voltage exceeding 12V will damage the product.

Feature:

✔5 / 12V DC Power supply, support U disk TF card USB hard disk interface;

✔Supports a variety of encoding formats MPEG-1, MPEG-2, MPEG-4, H264, and XVID video decoding up to 1280 * 720. Built-in 2-channel output.

✔ Dynamic setting function, smooth digital album playback, ''with 8 * 16 SDRAM'';

✔A computer pull-down menu setting, the operation is more convenient and comfortable;

✔Super compatible with various video formats, fine interpretation of full audio file formats;

✔Supports easy e-book functions for browsing TXT text

✔Support language (Chinese, English),

✔Support Video output: CVBS

✔Support audio output: stereo (R/L)

✔Can be configured with VFD / LCD / LED to perform various display functions;

✔Can support FAT32 large capacity portable hard disk formats (currently must reach 1.5A or more)

✔ Convenient and fast infrared remote control operation,

✔Supports HD video resolution (1280*720)

✔Supports image formats: JPEG, BMP, GIF, PNG;

✔Play video formats: MKV (MPEG2 / RMVB / WMV9 / XVID / H.264); AVI (XVID / H.264); MP4 / M4V (XVID / H.264); MOV (XVID / H.264); VOB (MPEG2), PMP (XVID / H.264); RM / RMVB (RV8 / 9); MPG (MPEG1 / MPEG2); FLV (H.263 / H.264); 3GP; DIVX, DAT, etc.;

16 audio playback formats: MP3, WMA, OGG, FLAC, AAC, APE, AC3, ATRA, Japan

17 e-book formats: TXT, LRC ,. C;

18 with AUX input

Settings:

Enter the parameter settings menu

1. Super compatible with standard formats such as DVD, SVCD, VCD, DVCD, DVIX, AVI, MKV, FLV, etc.

2. various voice-over languages ​​(English, French, Portuguese, German, Danish, etc.) multi-angle, multiple subtitles

3. Video output support: CVBS

4. Can configure VFD / LCD / LED to perform all types of functions

5. Supports HD video resolution (1280 * 720)

6. Supports image formats: JPEG, BMP, for Kodak images, CDG;

7. Supports smart upgrading

8 audio output radiance: greater than 750mv (1K0DB)

9. Power product consumption: 5V / 350mA

Key function:

1. PREVE: Last song/volume reduction (Short press on the previous track, long-press the volume down)

2. Next: next song/volume plus (Short press the song, long press volume plus)

3. Play: Press briefly play/pause.

Specification:

1. Supporting USB, TF card, Bluetooth wireless connection, infrared remote controller

2. Play MP3, MP4, MP5, WMA, lossless, Power-off memory playback

3. Supply 12V Power (Universal)

4. Radio FM87.5-108

5. LED digital tube display.

6. AUX voice input.

7. Shell size: 25 * 106MM

Package:

1x MP5 decoder board
1x Remote control (Without battery)
