IC IR2104S SOP-8 (SMD Dán) (IR2104 2104)

_x000D_ IC IR2104S SOP-8 (SMD Dán)

Mô tả:
IC GATE DRVR HALF-BRIDGE
Half-Bridge Gate Driver IC Non-Inverting

Thông số kỹ thuật:
- Product Category: Gate Drivers
- Manufacturer: Infineon
- Mounting Style: SMD/SMT
- Package / Case: SOIC-8
- Product: Half-Bridge Drivers
- Number of Drivers: 2 Driver
- Output Current: 130 mA
- Configuration: Inverting
- Rise Time: 100 ns
- Fall Time: 50 ns
- Supply Voltage - Max: 20 V
- Supply Voltage - Min: 10 V
- Operating Supply Current: 150 uA
- Minimum Operating Temperature: - 40 C
- Maximum Operating Temperature: + 125 C
- Type: High Side/Low Side
- Packaging: Reel
- Brand: Infineon Technologies
- Features: Synchronous
- Height: 1.5 mm (Max)
- Length: 5 mm (Max)
- Logic Type: CMOS, LSTTL
- Maximum Turn-Off Delay Time: 150 ns
- Maximum Turn-On Delay Time: 680 ns
- Number of Outputs: 2
- Output Voltage: 10 V to 20 V
- Pd - Power Dissipation: 625 mW
- Propagation Delay - Max: 820 ns

Datasheet:
https://www.infineon.com/dgdl/Infineon-IR2104-DS-vNA-EN.pdf?fileId=5546d462533600a4015355c7c1c31671
