[4 con] (SOP) IC Dán 74164 74HC164 SOP-14 (SMD) (74HC164D) (IC Thanh ghi dịch chuyển SIPO 8 bit)

IC 74HC164 74HC164D SOP-14 (SMD Dán) 8-BIT PARALLEL-OUT SERIAL SHIFT REGISTERS The SN74HC164N is a 8-bit parallel-out Serial Shift Register features AND-gated serial inputs and an asynchronous clear (CLR) input. The gated serial (A and B) inputs permit complete control over incoming data, a low at either input inhibits entry of the new data and resets the first flip-flop to the low level at the next clock (CLK) pulse. A high-level input enables the other input, which then determines the state of the first flip-flop. Data at the serial inputs can be changed while CLK is high or low, provided the minimum set-up time requirements are met. Clocking occurs on the low-to-high-level transition of CLK. Outputs can drive up to 10 LSTTL loads Fully buffered clock and serial inputs Direct clear Green product and no Sb/Br Applications Communications & Networking, Consumer Electronics, Imaging, Video & Vision .............................................................................. Điện tử Minh Nguyên CHIPN24 - Thời gian làm việc: + Từ T2-T7: 8h00' sáng - 6h00' tối + Riêng Chủ nhật: Từ 8h00' sáng - 3h00' chiều
