Creative Sound Blaster Z SBX PCIE SB1500

The Sound Blaster Z PCIe Soundcard from Creative Labs is a PCI Express compatible sound card featuring 116dB signal-to-noise ratio along with SBX Pro Studio technologies helping to provide 360° true-to-life surround sound.

116dB Signal-to-Noise Ratio

A signal to noise ratio or SNR of 116dB provides for enhanced audio when compared to standard motherboard audio

SBX Pro Studio Technologies

The SBX Pro Studio suite of technologies improves audio output and a 360-degree true-to-life sound stage

Crystal Clear Communication

Experience crystal clear communication with your teammates with the CrystalVoice suite of technologies that removes echoes, ambient noises and picks up your voice from within a zone (CrystalVoice Focus). It also maintains your voice level even if you move near or further away from the microphone.

Sound Blaster Beamforming Microphone

When used with CrystalVoice Focus, the bundled beamforming microphone creates an acoustic zone and suppresses noise outside it, enabling you to be heard with improved clarity.

Sound Core3D Audio Processor

The quad-core Sound Core3D audio processor was designed to offload SBX Pro Studio and CrystalVoice effects processing from your primary CPU, improving your overall PC performance.

Advanced Home Entertainment Audio

With Sound Blaster Z's gold-plated connectors, speaker optimization technology and digital content encoding capability you benefit from greatly improved digital audio.

High Fidelity Surround Sound

Connect to your home theater system through a single digital cable and take advantage of cinematic DVD movies by transforming any stereo or multi-channel streams into high fidelity surround sound.

Never Unplug Your Headphones Again

With the Sound Blaster Z-series Control Panel you can just toggle between your headphone and speaker system with the flip of a switch.

Output Level	Front Channel Out : 2Vrms
Maximum DAC Resolution	Front Channel Out : 24-bit, 192kHz
SNR	Front Channel Out : 116dB
Frequency Response @ 96kHz	Front Channel Out : 10Hz to 45kHz
Frequency Response @ 192kHz (Stereo only)	Front Channel Out : 10Hz to 88kHz

Supported Output Formats	Stereo/2.1 Speakers

Headphone	1 x Amplified 1/8" mini jack
Speaker Out	3 x 1/8" mini jacks
Optical Out	TOSLINK
Optical Input	TOSLINK
Line In / Microphone In	Shared 1/8" mini jack
System Requirements	Intel Core 2 Duo or AMD equivalent processor, 2.2GHz or faster recommended
Dimensions	Not specified by manufacturer
Weight	Not specified by manufacturer

Creative Labs Sound Blaster Z PCIe Soundcard

• Sound Blaster Beamforming Microphone
• Quick Start Leaflet
• Installation CD
• Limited 1-Year Manufacturer Warranty
