Bộ Chuyển Mạch Mạng 1000M Bộ Chuyển Mạch Để Bàn Đầu Cắm 5 Cổng Gigabit Mini Chuẩn EU Bộ Chia Mạng LAN Ethernet Nhanh Bộ Chia Mạng RJ45 Ethernet Và Bộ Chia Chuyển Mạch Shunt

• Origin:CN(Origin)
• Ftion:Stackable
• Model Number:TD-G5
• Transmission Rate:10/100/1000Mbps
• Certification:CE
• Switch Type:Gigabit Switch
• Package:No
• Communication Mode:Full-Duplex & Half-Duplex
• Power Input:100-240V ~ 50 / 60Hz
• Ports:5
• Standards:IEEE 802.3,IEEE 802.3u,IEEE 802.3x,IEEE 802.3ab

Product Overview

TD-G5 is a 5-Port Gigabit Desktop SOHO switch. It provides 5 10/100/1000Mbps auto-negotiation ports, which you can use to establish a LAN network, or extend the uplink network. Compared with a 100M switch, it enhances transmission speed up to 10 times, eliminating the bottleneck of cascading bandwidth. It supports desktop installation and wall-mounting. Without configuration, it can be played once plugged.
With the stable connectivity and easy-to-use features, it is perfectly fit for the networking of school dormitories, small offices, home offices and Video Surveillance.

Main Features

• 5 * 10/100 / 1000Mbps auto-negotiation ports
• Auto MDI / MDIX simplifies networking and maintenance
• Full wire speed forwarding ensures a smooth network experience
• Flow control for full duplex and backpressure for half duplex avoids frame dropping as port blocked
• Adopts store-and-forward mechanism and provides 2K MAC address table
• 15K Jumbo frame improves the forwarding speed of large data
• Adopts green and environmental ABS material, improving heat resistance and heat dissipation
• Allows IP camera accessing and provides a running and clear image
• Desktop and wall mounting simplify installation

5 Port Gigabit Network Switch 1000Mbps RJ45 LAN Desktop Fast Ethernet Switching HUB Shunt with EU/US Power Adapter for Home Monitor
Specification:
Model: TXE034
Plug Type: EU/US
Chipset: for MediaTek/MTK7530
Port Quantity: 5-Port 10/100/1000M Automatic MDI-MDIX RJ45
Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab
Internet Media:
10BASE-T: UTP 3, 4, 5 Cat Cable (Maximum 100m)
100BASE-TX / 1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Data Rate: 10/100/1000M
Forwarding Rate: 148,800 Pps At 100M
Working Temperature: 0℃~40 ℃
Relative Humidity: 10%~90% (No Condensation)
Storage Temperature: -40 ℃~70 ℃
Relative Humidity: 5%~90% (No Condensation)

Note:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3mm measuring deviation due to manual measurement.

1 X Desktop Switch
1 X Power Adapter
