diymore Mô Đun Nhận Rơ-le 4CH Công Tắc RF Cho Cổng Nhà Để Xe Điều Khiển Từ Xa Không Dây Thông Dụng 433MHz AC110V-220V

Clear data:
Press the control panel code pairing button 8 times continuously, the LED indicator will flash 8 times, then the LED indicator will automatically flash 8 times continuously, then the code clearing is completed, and all the remote control key codes that have been learned before are cleared.

Explanation of the output method:
1. Self-locking: Press the same remote control button, press it once, the relay will turn on, and press it again, the relay will turn off.
2. Interlocking: Press the "A" key of the remote control, the relay will be turned on, and press the "B" key of the remote control, the relay will be turned off.
3. Jog: press the "A" button of the remote control, the relay will be turned on, release the "A" button of the remote control, the relay will be turned off. If you keep pressing the "A" button of the remote control, the relay will be on all the time, and when you release the remote control, the relay will be off.


Precautions:
1. Do not operate with power on, the power should be turned off to operate, and the power should be turned on after the detection is confirmed.
2. When the voltage of the remote control is insufficient, please replace the battery in time (when the battery voltage of the remote control is insufficient, the general remote control distance becomes closer).
3. When using wireless electronic products, you should avoid metal masks, large electronic equipment, electromagnetic fields, etc. There are strong sources of interference, so as to avoid the remote control and the receiving distance being short or unable to work normally.


Package includes:
Switch transceiver module * 1 + 4 remote control * 1
